Product Details
Equivalent designations
UNS N07718
DIN W. Nr. 2.4668
Form | ASTM |
Rod, bar and forging | B 637 |
Plate, sheet and strip | B 670, B 906 |
Seamless pipe and tube | B 983 |
GB/T | UNS | Trademark | W.Nr | ||||
GH4169 | N07718 | Inconel718 | 2.4668 | ||||
Chemical Composition: | |||||||
Grade | % | Fe | Ni | Cr | Mo | Nb | C |
Inconel718 | Min | Rest | 50 | 17 | 2.8 | 4.75 | |
Max | 55 | 21 | 3.3 | 5.5 | 0.08 | ||
Mn | Si | S | Cu | Al | Ti | B | |
0.2 | 0.65 | ||||||
0.35 | 0.35 | 0.015 | 0.3 | 0.8 | 1.15 | 0.0006 | |
Physical Performance: | |||||||
Density | 8.25 g/cm³ | ||||||
Smelt Point | 1260-1320 | ||||||
H*T | T*S | Y*S | El | Hardness | |||
Rm N/mm2 | RP0.2N/mm2 | A5 % | HB | ||||
Solution | 965 | 550 | 30 | ≤363 | |||
Features:
Inconel 718 is an age-hardenable nickel-chromium alloy that combines corrosion resistance with high strength and good fabricability. It has high creep-rupture strength at temperatures up to 700℃. Its excellent relaxation resistance contributes to its application in springs.
Applications:
Gas turbine engines, rocket motors, nuclear reactors and spacecraft.
With wide experience and expertise, Beall Industry Group is one of the leading inconel718 manufacturers and suppliers. We have hundreds of high-qualified workers at your service. Please rest assured to get the competitive price inconel718 for sale with us.
Hot Tags: inconel 718 unsn07718 2.4668, China inconel 718 unsn07718 2.4668 manufacturers, suppliers, factory
